SZL series water tube steam boiler is also named automatic chain grate boiler, with D-type layout, horizontal style, low pressure and double-drum offset hearth. Fuel feeding method is automatic which saves a lot of labor. Suitable for large capacity 6tons/h. Compare with the previous boiler, the new type SZL boiler adopts membrane water cooling wall, low thermal inertia design, and water cooling combustion chamber.
Fuel: Except wood chips, the SZL series boiler could burn other biomass fuel as well, such as bamboo chips, straw, rice hull, peanut shell, bagasse, cotton stalk, coconut shell, corncob, waste cloth, etc.
Applications: Foods, Garment, Textile, Paper, Brewery, Ricemill, Printing & Dyeing, Poultry feed, Sugar, Packaging, Plywood, Building material, Chemical, etc.
Whole SZL series biomass boiler system includes grate, boiler body, economizer, dust collector, flue, air duct, induced draft fan, blower, slag remover, loading machine, water pump, deaerator, etc.
SZL Series Biomass Fired Steam Boiler:
Model | Rated Steam Capacity (t/h) | Working Pressure (MPa) | Thermal Efficiency (%) | Overall Dimension L×W×H (m) | Weight (t) |
SZL2-1.25/1.6/2.5 | 2 | 1.25/1.6/2.5 | 81 | 5.8×2.35×3.5 | 25 |
SZL4-1.25/1.6/2.5 | 4 | 1.25/1.6/2.5 | 81 | 7.8×2.4×3.6 | 32 |
SZL6-1.25/1.6/2.5 | 6 | 1.25/1.6/2.5 | 81 | 8×3×4.87 | 43 |
SZL8-1.25/1.6/2.5 | 8 | 1.25/1.6/2.5 | 81 | 8.1×3.2×5.7 | 63 |
SZL10-1.25/1.6/2.5 | 10 | 1.25/1.6/2.5 | 81 | 8.2×3.5×5.7 | 87 |
SZL12-1.25/1.6/2.5 | 12 | 1.25/1.6/2.5 | 81 | 10.6×3.6×5.7 | 100 |
SZL15-1.25/1.6/2.5 | 15 | 1.25/1.6/2.5 | 82 | 12.5×3.7×5.8 | 105 |
SZL20-1.25/1.6/2.5 | 20 | 1.25/1.6/2.5 | 82 | 13.8×4.2×5.8 | 140 |
SZL25-1.25/1.6/2.5 | 25 | 1.25/1.6/2.5 | 82 | 15.6×5×6.135 | 170 |
SZL30-1.25/1.6/2.5 | 30 | 1.25/1.6/2.5 | 82 | 17.7×8.5×9.5 | 210 |
Note:1.Parameter is for reference only, if any changes should follow the factory technical data. | |||||
SZL Series Biomass Fired Hot Water boiler:
Model | Rated Power (MW) | Working pressure (Mpa) | Supply water temperature (℃) | Return water temperature (℃） | Thermal efficiency (%） |
SZL1.4-0.7/95/70 | 1.4 | 0.7 | 95 | 70 | 80 |
SZL2.8-0.7/95/70 | 2.8 | 0.7 | 95 | 70 | 80 |
SZL4.2-1.0/95/70 | 4.2 | 1 | 95 | 70 | 80 |
SZL5.6-1.0/95/70 | 5.6 | 1 | 95 | 70 | 80 |
SZL7-1.0/95/70 | 7 | 1 | 95 | 70 | 80 |
SZL10.5-1.0/115/70 | 10.5 | 1 | 115 | 70 | 80 |
SZL14-1.0/115/70 | 14 | 1 | 115 | 70 | 80 |
Note: 1.Parameter is for reference only, if any changes should follow the factory technical data. | |||||
